12mm Laminate 2200 x 193 x 12 mm
SKU
You must be signed in to access pricing and add to cart. Sign here or register for a trade account here.
| Product Information | |||
|
Technical Data
|
|||
|
Product reference
|
Laminate | Origin | China |
|
Size (length x width x thickness/top)
|
2200 x 193 x 12mm |
Abrasion AS/NZS 4266.20: 2004 | AC5 Heavy Commercial |
|
|
Drop Lock System | FSC | N/A |
|
Pattern
|
1 strip - no pattern repeat in length of board. 6 pattern repeats with the floor system | Janka Hardness Rating | N/A |
|
Structure
|
Carb 2 HDF Core |
Slip Testing | AS/NZS 4586-2004 Wet: P2, Dry: D1 |
|
Edging
|
Bevelled | Australian reaction to fire - FLOOR | ASISO 9239-1:2003 CRF 5.2kwm2, smoke value 5% |
|
Pack Size
|
1.698m2 | Australian reaction to fire - WALL | N/A |
|
Pack Weight
|
18kg | Release of 4-Phenylcyclohexene | ASTM D5116 <0.005mg/m2/hr (max limit allowable 0.05) |
|
Pack Length
|
2200mm, 4 full length boards per pack | Release of Formaldehyde | ASTM D5116 0.008mg/m2/hr (max limit allowable 0.1) |
|
Top Layer (Lamella)
|
N/A | Swell Test AS/NZS 4266.8:2004 | 0% Swell (max limit 15%) after 24hr immersion |
|
Surface Finish
|
EIR Registered Embossed / Matt Finish | Total VOC | ASTM D5116 0.005mg/m2/hr (max limit allowable 0.5mg/m2/hr) |
|
Environmental Rating
|
A+ Green Building Council of Australia: Pass | Warranty - Domestic | 25 year wear, lifetime structural |
|
Surface Wear Rating
|
AC5 Heavy Commercial | Warrenty - Commercial | 5 year wear, lifetime structural |
|
Fully Bonded
|
No | * | Subject to compatible subfloor and correct installation (Refer Installation Instructions) |
|
Nailed
|
No | ||
|
Floating on underlay
|
Yes* | ||
|
Over under slab heating
|
Yes* | ||
